Thin PTFE skived sheet 0.5mm~6mm
- Ultra-thin skived processing — thin thin PTFE sheet available down to 0.5 mm
- Excellent dielectric strength and chemical inertness
- Smooth, non-stick surface, easy to die-cut or laminate
- Ideal for precision gaskets, flexible insulation, and miniature components
Request a Sample and Quotation:
WhatsApp: +86-13821173226
Email: sales@chn-rubber.com
Precision Thin PTFE Sheet (0.5mm - 6mm Skived Roll)
Hebei Xinda Sealing Material Co., Ltd. is a premier manufacturer of high-performance thin PTFE sheet solutions, specializing in the skived production process. Our thin PTFE sheet is available in a versatile thickness range from 0.5mm to 6mm, offering the perfect balance of flexibility and mechanical integrity. Unlike thicker molded plates, these skived sheets are produced in continuous rolls, making them the ideal choice for high-volume gasket fabrication and large-surface industrial linings.
- 1. Our factory produces thin PTFE sheets in various specifications.
- 2. Thickness: Up to 12 mm.
- 3. Width: Up to 2000 mm.
- 4. Thin PTFE sheets are available in standard grades, such as pure conventional PTFE and pure chemically modified PTFE.
Key Features of Our Thin PTFE Sheet:
- Exceptional Flexibility: Our thin PTFE sheet (under 6mm) can be easily rolled, bent, or wrapped around complex geometries without cracking or losing its sealing properties.
- Superior Surface Finish: The skiving process ensures a smooth, non-stick surface with consistent ptfe sheet thickness tolerances across the entire roll.
- High Dielectric Strength: These sheets act as excellent electrical insulators, even at minimal thicknesses like 0.5mm or 1mm, suitable for high-frequency electronics and aerospace components.
- Chemical & Thermal Mastery: Maintains 100% inertness to aggressive chemicals and remains stable in temperatures ranging from -180°C to +260°C.
Skived Thin PTFE Sheet Technical Specifications
| Test Item | Unit | Target |
| Density | g/cm³ | 2.1-2.3 |
| Tensile Strength | Mpa | ≥15.0 |
| Ultimate Elongation | % | ≥150 |
| Voltage | Kv/mm | 10 |
Product Specifications
| Thickness(mm) | Width(mm) | Length(mm) |
| 0.5-6 | 10-2000 | Unlimited |
PTFE sheets in irregular or non-listed sizes are available for custom fabrication to meet specific customer requirements.
Common Applications
- Chemical Tank Linings: Using thin PTFE sheet to create a corrosion-resistant barrier inside steel or plastic vessels.
- Gasket & Seal Fabrication: Precision-cut gaskets for pumps, valves, and piping systems where a thin, conformable seal is required.
- Electrical Insulation: High-temperature wraps and liners for transformers, motors, and capacitors.
- Non-stick Surfaces: Release sheets for heat-pressing equipment or food processing belts.
Need a Custom Size? > We provide precision custom cut services for all our thin PTFE sheet products.
Contact our sales team for a free sample and current pricing >>
