High-performance centrifugal pump gland packing
This PTFE-graphite centrifugal pump gland packing is engineered for stable sealing inside the centrifugal pump gland, combining the chemical resistance of PTFE with the thermal conductivity of graphite. Its low-friction performance supports continuous shaft rotation while maintaining controlled leakage and long service life in demanding pump applications.
Request a Sample and Quotation:
WhatsApp: +86 13821173226
Email: sales@chn-rubber.com
Hebei Xinda provides precision-engineered centrifugal pump gland packing designed to meet the rigorous demands of rotating shaft systems. Unlike static seals, a centrifugal pump gland requires packing that can handle continuous friction, high surface speeds, and thermal expansion while maintaining a controlled leakage for lubrication and cooling. As a leading gland packing manufacturer, we offer customized sealing solution.
Centrifugal Pump Gland Packing Data Sheet
| Features | Unit | Technical Specification |
| Temperature | ℃ | -250 ~ +280 |
| Pressure | Mpa | 10-25 (Centrifugal Force Resistance) |
| Loss on Ignition | ||
| Line Speed | m/s | 0-12 (Material Dependent) |
| Ph Value | 0-14 |
Suitable for packing seals of various valves, pumps, and reactors under high pressure and highly corrosive media.
Select according to working conditions:
- For High-Speed Water Pumps: Graphited PTFE Packing with high thermal conductivity to prevent shaft scoring.
- For Slurry & Abrasive Media: Aramid Fiber Reinforced Packing to resist particle erosion in the stuffing box.
- For Chemical Processing: Pure PTFE Gland Packing for universal chemical resistance (PH 0-14).
About centrifugal pump gland packing FAQ:
Q1: How much leakage is normal for a centrifugal pump gland?
A: A small amount of leakage (approx. 8-10 drops per minute) is essential for cooling and lubricating the centrifugal pump gland packing. Over-tightening can cause excessive heat and damage the pump shaft.
Q2: Which material is best for high-speed centrifugal pump shafts?
A: For high-speed applications, we recommend Carbon or Graphite-filled PTFE. These materials have superior heat dissipation compared to pure PTFE, preventing the packing from hardening or glazing.
